Open Body Garbage Tipper

Price 350000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Open Body Garbage Tipper Specification

Usage & Applications
Industrial

Surface Finish
Polished

Weight
1200 Kilograms (kg)

Trailer Type
Travel Trailer

Trolley Use
Industrial

Material
Mild Steel

Open Body Garbage Tipper Trade Information

Minimum Order Quantity
1 Number

Supply Ability
10 Per Month

Delivery Time
15 Days

About Open Body Garbage Tipper

An Open Body Garbage Tipper (also known as a Tipper Hopper or Dumper) is a specialized waste management vehicle designed for the primary collection and transport of municipal solid waste (MSW). Unlike closed compactors, the open-body design allows for rapid manual loading and easy transport of bulky or loose waste.

Technical Specification & Description

1. Superstructure & Body Design

Body Type: All-steel welded construction with a high-tensile strength floor and side walls to resist impact and corrosion.
Capacity: Typically ranges from 1.5 $m^3$ to 10 $m^3$ depending on the chassis (LCV or HCV).
Loading Height: Designed with a low-entry sill to facilitate manual loading or the emptying of handcarts/bins.
Floor Plate: Reinforced with MS sheets (typically 3mm to 5mm thickness) to withstand heavy abrasive waste.

2. Tipping Mechanism (Hydraulics)

Type: Rear-end tipping (typically 45 to 50 angle) for gravity-assisted unloading.
Hydraulic Cylinder: High-quality single or double-acting telescopic cylinders mounted at the front or underbody.
Control: A Power Take-Off (PTO) unit connected to the vehicle engine, operated via a lever inside the drivers cabin.

3. Key Features

Tailgate: Robust rear door with heavy-duty hinges and a secure locking mechanism (manual or hydraulic) to prevent leakage during transit.
Covering System: Provisions for a tarpaulin or PVC cover to prevent waste from flying out during high-speed transport (Mandatory for NGT/Urban local body compliance).
Sub-frame: A sturdy intermediate frame mounted on the truck chassis to distribute the load evenly.
